24V 12.5A Switching power supply AC DC adapter
XSG24012500MM

Power Adapter

Update

Product Electronics Parameter
Product name	24V 12.5A switching power supply AC DC adapter
Model number	XSG24012500
AC input	Input Voltage range:	90～264Vac
	Reted input voltage:	100～240Vac
	InputFrequency Range:	47～62hz
	Input current max:	5.0A
	Inrush current:	100A Max/240V
	Efficiency:	90% min
	No load input power	<0.5W
	Leakage current:	<0.75mA/240V
DC output	Output voltage:	24V
	Output voltage tolerance:	5%
	Rated output current:	12.5A
	Output current:	0～12.5A
	Ripple and noise:	<300mVp-p
	CV or CC	Optional
	Current limited:	Optional
	LED indicator	Green color
Protection	Over current protection	PASS
	Over voltage protection
	Short circuit protection
	Over Temp protection
Environment	Operating Temp:	0℃～+45℃
	Storage Temp:	-30℃～+70℃
	Relative Humidity:	10%～90%
	Vibration and shock	Meet MIL-STD-810D
Safety	Safety standard	EN62368, EN60335
	EMC/EMI	Meet FCC CLASS B,EN55032, EN55035
	EMS	EN61000－4－2
		EN61000－4－3
		EN61000－4－4
		EN61000－4－5
	A Harmonic source	Pass
	HI-pot: Primary to Secondary	3KVAC,5mA,60s
	Drop Test	As per UL regulation
	Burning test	100%,4-5 hours
Energy efficiency level		CEC level VI, Doe VI
Life	MTBF	50000 hours
Life	Warranty	3 years
Certificate	ETL, FCC, CE, UKCA, PSE

Model Name	Rated output voltage range (VDC)	Rated output current range (mA)	Max. output power (W)
XSECxxxyyyyzz, XSGxxxyyyyzz, XSExxxyyyyzz, XSECxxxyyyyyzz, XSGxxxyyyyyzz, XSExxxyyyyyzz, XSECxxxyyyy, XSGxxxyyyy, XSExxxyyyy, XSECxxxyyyyy, XSGxxxyyyyy, XSExxxyyyyy	12.0-16.8	10000-20000	292.0
	16.9-23.9	10000-18000	330.0
	24.0-38.0	9000-15000	378.0
	38.1-58.0	5500-9440	360.0
	58.1-88.0	4000-6200	360.0
