135W Desktop Adapter

Smart portable 135W series power supplies with desktop style and L151*W61*H39MM size. The ripple and noise is 120-150mV. AC Input is 100-240V, 50/60HZ, Input current is 2.5A max, it has fourchoices in IEC320-C6, IEC320-C14, IEC320-C8 and AC inlet fixed with adapter body. DC output of adapter provides from 3-73Vmax, output current 0.3A-10A, 135W max. It can meet your usage at HiFi sound system or industry equipment products, information devices, telecommunication devices, mobile phone chargers and set-top boxes, etc. MTBF (Mean Time between Failures) is 50,000HRS. OVP; OCP; SCP; Hiccup protection, automatic recovery protection characteristic make sure a better quality adapters. Besides, we keep a complete track of every step of production process to ensure the quality of our products. Random inspections are performed according to AQL standards. All adapters are 100% burn-in tested using automatic burn-in testers and 100% inspected using ATEs, Taiwan-purchased raw material undergo IQC, IPQC, and OQC Inspections. Customized DC output plugs and DC cable give you more choices.

135W series Power adapter comply safety standard of IEC62368, GB4943, EN60950, EN55022, EN61000, EN60335, J60950, UL60950-1, CSA C22.2, IEC60950-1, AS/NZS60950, and energy consumption with DOE; VI; Erp; Nrcan; MEPS. We have been awarded many certifications to meet the requirements of the international market, such as CULUS, TUV-GS, CE, BEAB, C-TICK, PSE-JET, K-MARK, TLC, CCC, IRAM, CB, EMC, and FCC. We have services of daily production output 5000ps, 5days sample leading time and 25days bulk order. We can be your one-stop supplier for ITE power suppliers and switching power supplies, as well as the wall plug and desktop adapters. For quality goods and fast services, start your partnership with us today!

AC Inlet:135W IEC320 C8 AC Inlet:135W IEC320 C14 AC Inlet:135W IEC320 C6 AC inlet: 135W Fixed AC Input
Size:L151*W61*H39.2MM Size:L151*W61*H39.2MM Size:L151*W61*H39.2MM Size:L151*W61*H39.2MM
Drawing Download Drawing Download
Drawing Download Drawing Download
135w-iec320-c8
135w-iec320-c14
135w-iec320-c6
135w-fixed-ac-input

Features of 135W Series Desktop Adapter

  • Up to 135W
  • Designed in the USA, Made in China
  • Global Certificates.
  • Case Material: PC, GE brand
  • Fanless Design.
  • Active PFC
  • Fully sealed by ultrasonic welding.
  • Capacitor imported from Taiwan.
  • AC inlet: IEC320-C6, C8, C14 and Fixed inlet optional.
  • Protection: Over Load/Over Voltage/Over Current/Over Temp/Short-Circuit.
  • LED indicator show work status
  • Meet Energy Efficiency VI, Comply with CEC VI, DOE VI.
  • Comply With The Newest Safety Standard: UL62368, EN62368, IEC62368.
  • Brand Power Cord and DC Wire matched our products.
  • Customized Label and DC connector.
Specification Sheet Download

Certifications
GSTUVDownload- Certificate No.: Z1A171194747010;Standard:EN62368(EN62368=EN60950+EN60065);
Verify website: https://www.tuev-sued.de/product-testing/certificates.
CE& EMCDownload- Certificate No.: A8A 17 11 94747 009;Standard:EN60950-1:2006/A2:2013;
Verify Website:https://www.tuev-sued.de/product-testing/certificates.
UL CB Download-Certificate No.:DK-69112-UL;Standard:UL60950;
Verify website: www.UL.com
FCC Download- Report No.:4788121683-1;Standard:FCC Part 15 Subpart B.
Verify website: www.UL.com
KC Download- Certificate No.: HU10934-18002A &HU10934-18003A;Standard: K 60950-1 (2011-12);
Verify website: http://www.ktc.re.kr
C-TICK Download-Certificate No.: 17AE07019A 001;Standard: AS/NZS CISPR 32:2015;
Verify website: www.anci.com
SAA Download- Certificate No.: SAA-172984-EA;Standard: AS/NZS60950:2015;
Verify website: www.saaapprovals.com.au.
RCMDownload- Certificate No.: POC17123654;Standard: AS/NZS 60950:2015 & SAA-172894-EA;
Verify website: https//equipment.erac.gov.au/Registration/EquipmentSearch.aspx?atn=public.
